CPUs:
|
Toshiba TLCS900H core (16-bit), 6.144 MHz, Z80 at 3.072 MHz for sound.
|
|
RAM:
|
12k for 900H, 4k for Z80
|
|
ROM:
|
64kb boot ROM
|
|
RAM:
|
128 kbytes
Banking is used to accommodate all the RAM and ROM
inside the 8502's 64 address space
|
|
Communications:
|
SIO 1 channel 19200 bps, 5-pin serial port
|
|
Resolution:
|
160x152 COLORS: 16 palettes per plane, 48 palettes.
|
|
Display:
|
160 x 152 dot TFT LCD
|
|
Colors available:
|
4096
|
|
Colors on screen:
|
146
|
|
Neo-Geo Pocket color mode:
|
20 colors out of 4096.
|
|
Sprites:
|
64 sprites per frame, 4 colors per sprite.
|
|
Scrolling:
|
2 scrolling planes, 8x8 character tiles, 4 colors each.
|
|
Sound:
|
PSG 6 tone simultaneous output. Stereo sound.
|
|
Standard Screen Composition:
|
Sprite screen, scrolling A screen, scrolling B screen, and the background
|
|
Memory:
|
Built-in lithium battery
|
|
Power Supply:
|
2 size AA dry batteries (AA alkaline battery recommended) or AC adaptor
|
|
Play duration:
|
about 40 hours (with alkaline dry cell batteries)
|
|
Scroll function:
|
Allows for priority display, windows, and character displays.
|
|
Dimensions:
|
130mm (w) x 80mm (h) x 30.5mm (d)
|
|
Weight:
|
145 Grams / 195 Grams (with batteries)
|
|
Cartridges:
|
Maximum 2 MB (16 Mbit) with 4-16Mbit flash memory.
|
